Wichard Single 1 3/8" (35mm) Ball Bearing Cheek Block

Item #

72120

Product Description

Wichard Single 1 3/8" (35mm) Ball Bearing Cheek Block

Features:

  • Weight: 1.5 oz. (43 g)

  • Sheave diameter: 1 3/8" (35mm)

  • Shackle Diameter: 13/64" (5mm)

  • Length: 2 3/64" (52mm)

  • Width: 1 29/64" (37mm)

  • Thickness: 51/64" (20mm)

  • Working load: 705 Lbs (320 kg)

  • Breaking load: 1980 Lbs (900 kg)

  • Rope Size: 5/16"-11/32" (8mm-9mm)

  • Forged Shackle: 13/64" (5mm)

    Applications

  • Cheek blocks applications for genoa sheets...

    Material

  • Grade 316L stainless steel head configuration

  • Grade 316L stainless steel load straps

  • Polycarbonate flanges

  • Composite saddle for cam models

  • Delrin ball bearings

  • Composite sheave
