Schaefer 1 x 1/8" Twin Sheet Lead Block

Item #

32-77

Product Description

Schaefer 1 x 1/8" Twin Sheet Lead Block

Specifications

  • Suits Track: 1" x 1/8" (25mm x 3mm) T-Track

  • Max Boat LOA: 27" (8m)

  • Max Sail Area: 315 sq. ft. (29 sq. m)

  • Displ.: 5000 lbs. (2270 kg)

  • Sheave Dia.: 1 1/2" (38mm)

  • Max Line Dia.: (2) 1/2" (2 x 13mm)

  • Length: 3 1/2" (89mm)

  • Width: 1 11/32" (34mm)

  • Height: 3 9/32" (83mm)

  • Bearing Height: 1 29/32" (49mm)

  • Safe Working Load: 2500 lbs. (1135 kg.)

  • Weight: 10 oz. (284 g.)
