Product Description
Ronstan Small Alloy Cam Cleat
Features:
Hot-forged and hard anodized cams for maximum wear and corrosion resistance
Low effort line entry and exit due to unique teeth, line entry geometry and smooth finish
Unique self-cleaning, self-lubricating slotted bearings ensure consistent high performance even when subjected to high static loads
Superior resistance to sand and salt
Multi-coil spring generates near constant torque Easy entry/release and secure cleating of even the smallest diameter lines
Suitable for addition to swivel cleat bases for control lines and sheets
Small cleat has aluminum cams and a composite base for maximum durability and light weight
Medium cleat has an aluminum base and cams for maximum rigidity
Composite base combining lightness and durability
Product Information
Engineered for Performance Intensive development efforts have produced this high performance range of cam cleats that provides unbeatable holding power while allowing easy cleating and releasing of control lines and sheets.
Alloy Cleats™ Aluminum cam models built for ultimate durability where high wear and high loads are encountered. Cams are hot-forged and hard anodized for maximum strength and corrosion resistance. Ronstan Alloy Cleat™ models are available in sizes small and medium. The medium cleat is built on an aluminum base for maximum rigidity whilst the small cleat has a composite base for an optimum blend of lightness and durability.
Slotted Bearings Self lubricating, self-cleaning slotted bearings provide lower frictional resistance, quicker response times and superior resistance to sand and salt than ball bearings which can deform under load.
Multi-Coil Spring The multi-coil spring recessed in the upper part of the cam generates near constant torque. This consistency ensures secure cleating of even the smallest lines with minimal abrasion or rope wear.
Unique Teeth and Entry Profiles Low effort line entry and exit due to unique teeth and entry geometry.
Advanced Composite Base Small cleat has a base produced from long fiber reinforced polymer to save weight while providing essential stiffness.
Customization A comprehensive range of specialist cleat accessories allow customization of the cleat set-up to optimize performance by controlling inward lead, outward lead, cleating and uncleating angle and height.
Total Control Swivel cleat bases further enhance the function of cleats providing articulation, and with some models setting of cleating angle and direction (up or down cleating) to allow control of lines and sheets from various positions on the boat.
Specifications:
Rope Ø: 3/32-5/16 in. (2-8mm)
Height: 3/4 in. (20 mm)
Width: 1 in. (24 mm)
Length: 1 7/8 in. (48 mm)
Fastener Ø: 5/32 in. (M4)
Fastener Hole Centers: 1 1/16 in. (27 mm)
M.W.L.: 165 lb. (75 kg)
B. L.: 330 lb. (150 kg)
Weight: 0.9 oz. (25 g)
Materials
Hard anodized aluminum cams
Built on hard anodized aluminum base
